23 69-2245EF
Power supply: powered by the zoning module (24 to 34 VDC)
Default setpoint range: 41 °F to 100 °F (5 °C to 38 °C)
Default floor limit (AF mode): 41 °F to 100 °F (5 °C to 38 °C)
Setpoint interval: ± 1.0 °F (0.5 °C)
Indoor temperature display range: 32 °F to 158 °F (0 °C to 70 °C)
Outdoor temperature display range: -58 °F to 212 °F (-50 °C to 100 °C)
Display resolution: ± 1.0 °F (0.5 °C)
Operating temperature: -4 °F to 130 °F (-20 °C to 55 °C)
Storage temperature: -20 °F to 130 °F (-30 °C to 55 °C)
Humidity rating: 5% to 90% RH, non-condensing at 95 °F (35 °C)
Controller type: Proportional Integral (PI)
Memory type: All settings are stored in non-volatile memory and are not erased
during a power outage
Technical Specifications
400-146-001-A_69-2245EF (AQ1000TP2) ENG.fm Page 23 Wednesday, June 18, 2008 2:32 PM
