6 69-2005EF
The thermostat generally displays the actual (measured) temperature. To display the
setpoint temperature, press one of the buttons once. The setpoint will be
displayed for the next 5 seconds. An arrow appears at the left of the setpoint
temperature display.
To change the setpoint, press one of the buttons until the desired temperature is
displayed. To scroll faster, press and hold the button.
Error Messages
The measured temperature is below the thermostat’s display range.
The measured temperature is above the thermostat’s display range.
Verify the thermostat and external (floor) sensor connections.
Temperature Display and Setting
400-146-000-A_69-2005EF (AQ1000TN2) ENG.fm Page 6 Thursday, October 5, 2006 8:29 AM
