AQ25A SERIES PROGRAMMABLE BOILER CONTROL PANELS
69-2119—02 28
EDIT SINGLE ZONE Ambient/Floor Style (continued)
FLOOR LIMIT HI
a
41°F to 100°F
(5ºC to 38 °C)
100°F
(38°C)
Maximum floor temperature allowed for a given zone that is
controlled by a floor / slab sensor connected to that zone's
AQ1000 thermostat. At floor maximum, the zone
equipment is turned off. The FLOOR MAX cannot be set
below the FLOOR MIN setting.
FLOOR LIMIT LO
a
41°F to 100°F
(5ºC to 38 °C)
41°F
(5°C)
Minimum floor temperature allowed for a given zone that is
controlled by a floor / slab sensor connected to that zone's
AQ1000 thermostat. At Floor MIN, the zone equip is
energized. The FLOOR MIN cannot be set above the
FLOOR MAX setting.
SETPOINT VACANCY
HEAT
41°F to 100°F
(5ºC to 38 °C)
41°F
(5°C)
Target HEATING temperature for the zone when system is
in VACANCY mode.
SETPOINT VACANCY
COOL
41°F to 100°F
(5°C to 38°C)
100°F
(38°C)
Target COOLING temperature for the zone when system is
in VACANCY mode.
Only displays when cooling is enabled for that zone.
CHANGEOVER 2°F to 9ºF
(1ºC to 5ºC)
2°F
(1ºC)
Temperature deadband that determines the changeover
from heating to cooling and from cooling to heating:
• The thermostat switches from heating to cooling mode
when the indoor temperature is higher
than the setpoint
by more than the changeover band setting for 15
minutes.
• The thermostat switches from cooling to heating mode
when the indoor temperature is lower than the setpoint
by more than the changeover band setting for 15
minutes.
KEYBOARD LOCK or
UNLOCK
UNLOCK Controls the zone thermostat's keyboard.
• If set to LOCK, settings cannot be changed at that
zone's thermostat.
• If set to UNLOCK, the floor thermostat's settings can be
changed within the FLOOR MAX and FLOOR MIN
limits.
PROGRAM SETTINGS
Displays, and allows for editing of, the temperature setpoints for each of the four time
periods (or programs) within a 24-hour period (WAKE, LEAVE, RETRN (return), and SLEEP).
MODE AUTO,
OCC, or
UNOCC
AUTO • AUTO = Automatically follow the four time periods (or
programs) within a 24 hour period, as set up in the Edit
All Days or Edit Daily sub-menus. The four programs
are WAKE, LEAVE, RETRN (return), and SLEEP.
• OCC = Observe the program settings only for WAKE
and RETRN (return).
• UNOCC = Observe the program settings only for
LEAVE and SLEEP.
EDIT ALL DAYS ALL WAKE,
ALL LEAVE,
ALL RETRN, or
ALL SLEEP
WAKE=6:00AM
LEAVE=8:00AM
RETRN=6:00PM
SLEEP=10:00PM
Allows Installer to set the WAKE, LEAVE, RETRN (return),
and SLEEP times once, and apply the settings to all 7
days.
NOTE: The programs will be copied to the individual days
only
when the COPY TO ALL DAYS option is
selected.
EDIT DAILY WAKE,
LEAVE,
RETRN, or
SLEEP
WAKE=6:00AM
LEAVE=8:00AM
RETRN=6:00PM
SLEEP=10:00PM
Allows Installer to set the WAKE, LEAVE, RETRN (return),
and SLEEP times for all 7 days individually.
Table 5. User Menu. (Continued)
Menu Option Range
Factory
Default Description
To Next Page
