Honeywell AQ25A Series User Manual

AQ25A SERIES PROGRAMMABLE BOILER CONTROL PANELS
39 69-2119—02
Fig. 26. Installer Menu Structure. – Test and Purge.
M27772
INSTALLER MODE
ARE YOU SURE? NO
YES
INSTALLER MODE
EQUIPMENT SETUP 
TEST AND PURGE 
EXIT INSTALLER 
INSTALLER MENU
BOILER PUMP: OFF 
AUX. PUMP: OFF 
DHW PUMP: OFF 
BOILER T-T: OFF 
AUX OUT: 0FF 
TEST OUTPUTS
OUTDOOR:
BOILER:
RETURN:
DHW:
TEST SENSORS
ALL ZONES: OFF 
ZONE A-1: 0 OFF 
...
ZONE D-16: 0 OFF 
TEST ZONES
PURGE TIME: 5:00 
PURGE: ALL 
START PURGE:
PURGE OFF:
PURGE
TEST OUTPUTS 
TEST SENSORS 
TEST ZONES 
PURGE 
TEST AND PURGE
1
THE  SYMBOLS INDICATE ADDITIONAL SELECTIONS ARE POSSIBLE.
THE FACTORY DEFAULT VALUES ARE SHOWN.
1

Honeywell AQ25A Series Specifications

General

Brand	Honeywell
Model	AQ25A Series
Category	Control Panel
Language	English
