8 Maintenance
enCore FC
Operating Instructions
Page 103 of 120
► Remove the 4 mounting screws (A) from the left side wall.
Fig. 8-1
►
Remove the left side plate.
Fig. 8-2
Fig. 8-3 F
ig. 8-4
►
Carefully loosen the battery cover tabs (B) using a small screwdriver.
► Remove the battery cover tabs.
► Take out the old battery.
A
B
A
