Controller Information
2-2 SVP Controller Operation Manual Part No.: 44200004 - Revision 2
2.2.2 General
The SVP Controller can be configured through the wired Ex i interface with
a Local Access Device (LAD).
The LAD (Local Access Device) is a hand held controller used to interface
with the Fusion4 product family, allowing tasks such as parameter
adjustment, alarm resetting, and calibration. The device facilitates two-way
data communications between the SVP Controller and the LAD, allowing
the rapid transfer of transaction data, configuration files and calibration
records, and even firmware upgrading while in the field.
Figure 2-1: The Local Access Device (LAD) and its system overview
2.2.3 Commissioning
The LAD is used to commission the SVP Controller by configuring entities
(or parameters) to the desired specific values. This is done by using the
LAD to navigate through the Menu functions of the SVP Controller
(See 2.3.4).
