Controller Information
Part No.: 44200004 - Revision 2 SVP Controller Operation Manual 2-17
2.3.9.1.1 Transaction information
The details of any transaction can be viewed by going to that transaction
and pressing OK. After every prover run cycle in calibration of meter mode
the following parameters will be logged after completing the prover run
Transaction ID
Stop Transaction date and time
Cycle count
Sweep time
Alarm information
Sensor Pair
Device Serial Number
Transaction record version
2.3.9.2 Calibration Logs
The details of any transaction can be viewed by going to that transaction
and pressing OK. After every prover run cycle in prover calibration mode
the following parameters will be logged after completing the prover run.
The calibration log contains the following information:
Date and time
Sweep time in seconds
Average volume
Repeatability
There are no units displayed for the average volume as they will be
known by the user and to avoid complications if the units specified in the
Configuration/Device/Units menu are changed.
2.3.9.3 Alarm Logs
The Alarm log forms a permanent record of the same information that
can be viewed while an alarm is active from the Diagnostics/Active
Alarms screen. This information consists of the date and time stamp and
descriptive text.
