Controller Information
Part No.: 44200004 - Revision 2 SVP Controller Operation Manual 2-3
2.3 Menus and Navigation
2.3.1 General
An intuitive and informative Human Machine Interface (HMI) is available to
the user to operate, configure, and service the SVP Controller. This
menu-based user interface is as clear and accessible as possible, using
easily understandable colored icons for the Main Menu and logically
structured sub-menus.
2.3.1.1 Key benefits
Clean, intuitive, and informative user interface
No need to memorize parameter codes, enumeration value
Diagnostic screens
Record-based approach to transactions and calibrations make
re-use possible
Interoperable with the Local Access Device (LAD)
Provides a graphical user interface to the LAD
2.3.2 Main Menu
Title
Main Menu icon
Name of selected item
Only available
if LAD is connected
Selected item
(focus rectangle)
Figure 2-2: Main Menu
