Controller Information
Part No.: 44200004 - Revision 2 SVP Controller Operation Manual 2-5
2.3.3.3 Enumeration Input Screen
Scrollbar
Action message
Focus rectangle
Figure 2-5: Enumeration Input Screen
2.3.3.4 Status Bar
Figure 2-6: Status Bar
Always visible on all screens
Contains the following information:
• Context-specific information/directions to user
• Status of the transactions (e.g., Idle, Running, Error)
• Device Locking Icon
2.3.4 Menu Structure
For a high level overview of the entities and parameters, see the
following diagram (Figure 2-7).
For a detailed view of all menu items, see the individual section.
Continued on next page
