Part No.: 44200004 - Revision 2 SVP Controller Operation Manual 2-1
CHAPTER 2 CONTROLLER INFORMATION
2.1 Initial Power up
Upon initial power up of the SVP Controller the Prover Status screen will
be displayed showing the operating mode of the prover (Meter Calibration,
Prover Calibration, or Prover Test) and the following information:
Piston status or position
Motor status
Error status
Number of cycles
Stop time
Sweep time
An example of a Prover Status screen is shown below.
Prover Status · Meter Calibration
Piston Parked Position
Motor Idle
Error Status No Error
Cycle 776
Stop Time 10-31-12 11:29:32 AM
Sweep Time 00:00:01:102
Press OK to enter menu Stop
2.2 Navigating the SVP Controller Menus Using the LAD
Pressing the OK button on the Local Access Device (LAD) will result in the
Main Menu screen being displayed on the SVP Controller.
2.2.1 Text Conventions
In the following sections of this document the entity and entity related text
are shown in a distinctive format as shown below.
All [Entity] and <entity-related> text is recognizably formatted.
