Specifications
OPERATING CHARACTERISTICS
Scanning Range Standard 0.5 to 40.0 m (1.64 to 131.2 ft)
Low temperature 0.5 to 20.0 m (1.64 to 65.6 ft)
Long range 30 to 75 m (98.4 to 246 ft)
Minimum Detected Object Size 40 mm (1.57 in.) diameter
Effective Aperture Angle ± 2° meets IEC 1946-2 requirements
Emission infrared, pulsed, 880 nm, two selectable
emission frequencies
Immunity to Ambient Light Sun 20,000 lux
Lamplight 15,000 lux
ELECTRICAL CHARACTERISTICS
Power Supply Voltage 120 Vac / 240 Vac , + 10 %, -20 % 24 Vdc, ± 15 %
Power Supply Frequency 48 to 62 Hz —
Power Consumption Standard & Long range :
E = 4 VA / 3W
R = 6 VA / 5W
Lens Heating :
E = 7 VA
R = 9 VA
Output Switching Capacity 2 A/250 Vac, 2 safety relays with guided contacts (10 mA min.)
Response Time 20 ms OFF (140 ms ON)
Electrical Wiring Snap-in clips or DIN 43652 connector
Noise Immunity Electrical: IEC 801-4, level IV
Electromagnetic: IEC 801-3, level IV
ENVIRONMENTAL/PHYSICAL CHARACTERISTICS
Ambient Temperature Standard and long range versions 0° to +55°C (32° to +131°F)
Low temperature version -25° to +55° C (-13° to
+131°F)
Sealing Terminal IP 67 or NEMA 6
Quick connect IP 65 or NEMA 4 and 13
Dimensions Housing terminal 187 mm (7.36 in.) high
120 mm (4.72 in.) deep
50 mm (1.97 in.) wide
Housing quick connect 277 mm (10.90 in.) high
120 mm (4.72 in.) deep
Emitter lens diameter 35 mm (1.38 in.)
Receiver lens diameter 40 mm (1.57 in.)
Material Housing Aluminum alloy, yellow
painted according to RAL
1021 (polyurethane)
Front face Polycarbonate
Mass (per module) Emitter 1,150 g (2.5 lb.)
Receiver 1,350 g (3 lb.)
