Honeywell FF-SPS4 Series User Manual

107063-11 EN FR26 GLO 800 Printed in France 65
Order Guide
• lens heating models
Scanning
range
Connecting
terminals
Supply
voltage
Complete sets Temperature
range
Emitter Receiver
120 Vac FF-SPS42TRE FF-SPE42TXE FF-SPR42TRE0.5 to 20 m
(1.65 to 65 ft.)
terminal strips
(snap-in-clips)
IP 67
240 Vac FF-SPS42TRG
-25° to 50°C
(-13° to 122°F)
FF-SPE42TXG FF-SPR42TRG
• standard models
Scanning
range
Connecting
terminals
Supply
voltage
Complete sets Temperature
Range
Emitter Receiver
120 Vac FF-SPS44CRE FF-SPE44CXE FF-SPR44CRE
240 Vac FF-SPS44CRG FF-SPE44CXG FF-SPR44CRG
metal
connectors
(DIN 43652)
IP 65
24 Vdc FF-SPS44CR2 FF-SPE44CX2 FF-SPR44CR2
120 Vac FF-SPS44TRE FF-SPE44TXE FF-SPR44TRE
240 Vac FF-SPS44TRG FF-SPE44TXG FF-SPR44TRG
0.5 to 40 m
(1.65 to 131 ft.)
terminal strips
(snap-in-clips)
IP 67
24 Vdc FF-SPS44TR2
0° to 50°C
(32° to 122°F)
FF-SPE44TX2 FF-SPR44TR2
• long range models
Scanning
range
Connecting
terminals
Supply
voltage
Complete sets Temperature
range
Emitter Receiver
120 Vac FF-SPS47CRE FF-SPE47CXE FF-SPR47CRE
240 Vac FF-SPS47CRG FF-SPE47CXG FF-SPR47CRG
metal connectors
(DIN 43652)
IP 65
24 Vdc FF-SPS47CR2 FF-SPE47CX2 FF-SPR47CR2
120 Vac FF-SPS47TRE FF-SPE47TXE FF-SPR47TRE
240 Vac FF-SPS47TRG FF-SPE47TXG FF-SPR47TRG
30 to 75 m
(98.4 to 246 ft.)
terminal strips
(snap-in-clips)
IP 67
24 Vdc FF-SPS47TR2
0 to +50°C
(32° to 122°F)
FF-SPE47TX2 FF-SPR47TR2
Mirrors
FF-MSK1 Individual mirror on metal plate with several mounting holes, 25% scanning range
reduction.
FF-SPZ01MIR Individual adjustable mirror (includes tube adapter, mirror plate, and brackets) for
a single beam; 10% scanning range reduction.
FF-SCZ02MIR Post with two individual mirrors (located 400 and 900 mm from floor); 10%
scanning range reduction.
FF-SCZ03MIR Post with three individual mirrors (located 300, 700, and 1100 mm from floor);
10% scanning range reduction.
FF-SCZ04MIR Post with four individual mirrors (located 300, 600, 900, and 1200 mm from floor);
10% scanning range reduction.
FF-SPZ11 MIR Individual adjustable mirror (includes tube adapter, mirror plate, and brackets) for
a single beam; 25% scanning range reduction.
1
240 Vac available upon request
*For scan ranges below 30 m (98.4 ft.), use standard range products
