Honeywell FF-SPS4 Series User Manual

42 107063-11 EN FR26 GLO 800 Printed in France
Connections
Overview
This section contains information about electrical connections and wiring. The FF-SPS4 Series
safety perimeter guard devices are easy to install using quick-connect and terminal strip style
termination.
IMPROPER INSTALLATION
Strictly adhere to all electrical connection instructions.
Failure to comply with these instructions could result in death or serious injury.
Terminations
Quick-connect Style
The quick-connect style termination is a metal connector. The user emitter connector catalog
listing is FF-SBZ1721137 and the user receiver connector catalog listing is FF-SBZ1721202.
Figure 3-1 illustrates the metal quick-connect connector as viewed from the rear. Both
connectors use the same type of crimped pins and are provided with each quick-connect
product.
Figure 3-1 Quick-connect Connector (rear view)
