vii 107063-11 EN FR26 GLO 800 Printed in France
Directives Compliance
Machine Directive 98/37/EC
Low Voltage Directive 73/23/EC
Electromagnetic Compatibility Directive 89/336/EC
Control Reliability
Control Reliability means that “the device, system or interface shall be designed, constructed
and installed such that a single component failure within the device, interface or system shall
not prevent normal stopping action from taking place but shall prevent a successive machine
cycle.” (ANSI B11.19-1990, 5.5)
OSHA 29 CFR 1910.217 states that “the control system shall be constructed so that a failure
within the system does not prevent the normal stopping action from being applied to the press
when required, but does prevent initiation of a successive stroke until the failure is corrected.
The failure shall be detectable by a simple test, or indicated by the control system.”
Honeywell has developed self-checking techniques which combine control reliability with
safety. The FF-SPS4 Series perimeter devices function with dual channel redundancy and
positive self-checking monitoring. This means that a faulty component in our system will make
the safety barrier fail in a safe mode.
This design meets the requirements for Category 4 Electrosensitive Protective equipment as
described in the EN 61496-1/2 European standard. Category 4 safety products are designed
and manufactured in such a way that a single breakdown or an accumulation of failures does
not lead to the loss of the safety function when a dangerous situation arises. The safety
function is maintained on a permanent basis.
Organization of Manual
This installation manual consists of the following sections:
Important Information contains important highlighted information, the manual’s
organization, control reliability information, approvals, standards, regulations and directives.
Description and Operation discusses operation and specification information.
Installation explains how to properly mount and align the FF-SPS4 device. The calculation
of safety distance is also discussed.
Connections covers electrical connection and wiring diagram information.
Inspection and Maintenance contains operational test, inspection, maintenance,
troubleshooting and repair information.
Order Guides provide catalog listings of single beam devices, accessories, and spare parts.
Warranty Information provides important contact information related to sales and service.
Index contains keywords and their associated pages related to topics found throughout this
manual.
