Honeywell FF-SPS4 Series User Manual

62 107063-11 EN FR26 GLO 800 Printed in France
Figure 4-3 Fuse Location
Emitter Board Receiver Board
Power supply
fuse location
Power supply
fuse location
Ground Connection
1. If the perimeter guarding device is a quick-connect version, ensure the ground is
connected securely to the screw in the user plug.
2. If the perimeter guarding device is a terminal strip version, remove the cover (see Fuse
Replacement) and ensure the ground connection is connected securely to the screw
located at the bottom right.
3. Perform the operational test to ensure proper functional readiness.
