Mounting Hardware
The FF-SPS4 Series perimeter devices are delivered with rotatable brackets and include the
hardware necessary to install them (see figures 2-12 and 2-13). The bracket is fastened to the
bottom of the perimeter device. Two additional holes, located at the back of the device, can
also be used to install the product. However, the customer must supply the brackets if the
holes on the back are used.
Figure 2-12 Rotatable Mounting Brackets
Figure 2-13 Mounting Bracket Dimensions (for reference only)
2 CHC screws
(key nb 5)
