Figure 2-15 Single-beam Mirror (FF-SPZ01MIR/FF-SPZ11MIR) Mounting (for reference
only)
FSP25
123,5 x 103,5
(4.86 x 4.07)
8,5
(0.33)
17,0
(0.67)
14,0
(0.55)
9,0
(0.35)
(1.38)
Note : -35° ≤ α1 ≤ +35° if ß=0° or 180°
Note : -45° ≤ α2 ≤ +45° if ß=0° or 180°
3 CHC screws (key nb 3)
3 CHC screws (key nb 3)
