MS-5UD & MS-10UD Series Manual — P/N 52626:C2 1/24/2012 11
MS-10UD Series Main Circuit Board
4
6
6
4
T
B
6
Z
O
N
E
6
Z
O
N
E
7
Z
O
N
E
8
Z
O
N
E
9
Z
O
N
E
1
0
S
W
1
T
B
4
/
T
B
6
1
/
6
2
/
7
3
/
8
5
/
1
0
4
/
9
Notes: 1. MS-10UD-3(E) = 2.5 amps max. per NAC
MS-10UD-7(C/E) = 3 amps max. per NAC
2. Remote Sync Output is required only for
the MS-10UD-3(E): refer to “Remote Synchronization Output” on page 34.
3. 18 Amp Hour max. for MS-10UD-3(E)
26 Amp Hour max. for MS-10UD-7(E) 18 Amp Hour max. for MS-10UD-7C
Dummy load all unused circuits
with 4.7K, ½ watt End-of-Line
resistors
Style Z (Class A) NAC
Style D (Class A) IDC
Class A Converter Module
3 Programmable Relays
Nonsupervised relay contacts Contact Ratings 2.0 amps @ 30 VDC (resistive) 0.5 amp @ 30 VAC (resistive) Contacts shown below in normal condition (AC power with no alarm, trouble, or supervisory activity) A Fail Safe Trouble relay switches to the NC position during trouble conditions and under loss of all power. (*Factory default relay programming)
Alarm*
Trouble*
Supervisory*
Remote
Synchronization
Output (see note 2)
Special Application Power
24 VDC filtered, supervised,
and power-limited. 0.040 amp
maximum. Requires 4.7K
ohm ELR.
Class A Converter Module
Remove jumper JP43 to disable Ground Fault Detection circuit (only with approval of AHJ)
Cut this jumper to supervise the 4XTMF module when installed (see J4 & J5)
Cut this jumper to enable Supervisory Relay when 4XTMF module is installed
Auxiliary
Trouble Input
Kiss-off LED
Secondary Phone Active LED
Primary Phone Active LED
Primary
Secondary
ANN-SEC
option card connector
USB port for local programming using a personal computer and PK-5X Utility
DACT Phone Line Jacks
Nonpower-Limited
Battery (see note 3)
24 VDC, supervised,
nonpower-limited
Basic System Connections
10-Zone Panel
Power Supply Connector
For more specific UL wiring information, refer to page 35.
Important! Removing Ground Fault Disable Jumper JP43 voids UL/NFPA Style/Class indentifications for circuits. Remove jumper JP43 only with the approval of the local AHJ (Authority Having Jurisdiction).
Special Application DC Power Outputs 24 VDC) Nonsupervised, power-limited circuits Supervise with a power supervision relay EOLR-1 Resettable Power - 24 VDC filtered, power-limited (0.5 amp maximum) to smoke detectors (IDC). Supervision required. Nonresettable or Resettable Power Jumper selectable by JP31, 24 VDC filtered, power-limited (0.5 amp maximum). Supervision required. Nonresettable Power suitable for powering smoke detectors. Configure TB9, Terminals 1 & 2 as Resettable or Nonresettable Power. • Resettable Power - jumper JP31 pins 2
& 3
• Nonresettable Power - jumper JP31 pins
1 & 2 (as shown)
4 3
2 1
{
{
Notification Appliance Circuits (see note 1)
Special Application Power
NAC #1, #2, #3, & #4, Style Y (Class B) (Supervised, Power-
Limited) (See Style Z illustrated near right edge of board.)
4.7Kohm, ½ watt End-of-Line Resistor
PN 71252
NAC #1 NAC #2 NAC #3 NAC #4
Special Application
Power
IDCs 1 through 5, Style B
(Class B) (Supervised,
Power-Limited) (See
Style D illustrated near
right edge of board.)
4.7Kohm, ½ watt End-of-
Line Resistor
PN 71252
Initiating Device Circuits
Push switch down to
upgrade software
Special Application Power
IDCs 1 through 5, Style B
(Class B) (Supervised, Power-
Limited) (See Style D
illustrated near right edge of
board.)
4.7Kohm, ½ watt End-of-Line
Resistor
PN 71252
Initiating Device Circuits
