MS-5UD & MS-10UD Series Manual — P/N 52626:C2 1/24/2012 15
Specifications Product Description

ANN-RLY Relay Module
 ANN-LED Annunciator Module
• 80-character LCD display (backlit)
• Real-time clock/calendar with daylight savings time control
• History log with 256 event storage
• Control Buttons
 ACK (Acknowledge)
 Alarm Silence
 System Reset/Lamp Test
 Drill
• LED Indicators
 Fire Alarm
 Supervisory
 Trouble
 AC Power
 Alarm Silence
 Primary and Secondary Phone Line Active LEDs
• Piezo sounder for alarm, trouble and supervisory
• 24 volt operation
• Low AC voltage sense
• Alarm Verification
• NACs Programmable for:
 Silence Inhibit
 Auto-Silence
 Strobe Synchronization (System Sensor, Wheelock, Gentex, Faraday, Amseco)
 Selective Silence (horn-strobe mute)
 Temporal or Steady Signal
 Silenceable or Nonsilenceable
• Automatic battery charger with charger supervision
• Silent or audible walktest capabilities
• Optional PK-CD (contains PS-Tools utility) for local or remote Upload/Download of program
and data
• Optional CAC-5X Class A Converter Module for NACs and IDCs
• Optional 4XTMF Transmitter Module
• Optional ANN-SEC card for a secondary ANN-BUS
1.2 Specifications
AC Power
MS-5UD-3 (FLPS-3 Power Supply): 120 VAC, 60 HZ, 1.00 amps
MS-5UD-7 (FLPS-7 Power Supply): 120 VAC, 60 HZ, 3.90 amps
MS-5UD-7C (FLPS-7 Power Supply): 120 VAC, 60 HZ, 3.90 amps
MS-10UD-3 (FLPS-3 Power Supply): 120 VAC, 60 HZ, 1.00 amps
MS-10UD-7 (FLPS-7 Power Supply): 120 VAC, 60 HZ, 3.90 amps
MS-10UD-7C (FLPS-7 Power Supply): 120 VAC, 60 HZ, 3.90 amps
NOTE: For wiring specifications, refer to“Wire Requirements” on page 153.
