Honeywell HC30W45R2 Configuration Guide

Performance Series IP Camera Software Configuration Guide
36
In this way, you may set up an ROI window as a privacy mask by covering a protected area
using an ROI window, while the rest of the screen becomes the non-interested area. You
may then configure the non-interested area to have a high image quality, or vice versa.
Bit rate control
Constrained bit rate
A complex scene generally produces a larger file size, meaning that higher bandwidth will be
needed for data transmission. The bandwidth utilization is configurable to match a selected
level, resulting in mutable video quality performance.
• Target quality: Select a desired quality ranging from Medium to Excellent. If you select
Customized, you can enter a value to specify the quality.
• Maximum bit rate: Select a bit rate from the dropdown list. The bit rate ranges from
20kbps to a maximum of 40Mbps. If you select Customized, you can enter a value to
specify the maximum bit rate.
• Policy: If Frame rate priority is selected, the camera will try to maintain the frame rate per
second performance, while the image quality will be compromised. If Image quality
priority is selected, the camera may drop some video frames in order to maintain image
quality.
Fixed quality
All frames are transmitted with the same quality.
• Quality: Select a desired quality ranging from Medium to Excellent. If you select
Customized, you can enter a value to specify the quality.
• Maximum bit rate: Select a bit rate from the dropdown list. The bit rate ranges from 1
Mbps to a maximum of 40Mbps. If you select Customized, you can enter a value to
specify the maximum bit rate.
The Maximum bit rate setting in the Fixed quality configuration can ensure a reasonable
and limited use of network bandwidth. For example, in low light conditions where a Fixed
quality setting is applied, video packet sizes can tremendously increase when noises are
produced with electrical gains.
Configuring Audio Settings
Go to Setup Camera Setup  Audio.
Note Only HC30WF5R1 supports this function.

Honeywell HC30W45R2 Specifications

General

Windows operating systems supported	Windows 10, Windows 7
DC-in jack	Yes
Ethernet LAN (RJ-45) ports	1
Lens diameter	2.8 mm
Fixed focal length	2 mm
Maximum aperture number	2
DC output voltage	12
Power source type	DC, PoE
Power consumption (max)	12.95 W
Operating temperature (T-T)	-30 - 60 °C
Operating relative humidity (H-H)	0 - 90 %
Wi-Fi	No
Number of users	10 user(s)
Ethernet interface type	Gigabit Ethernet
Bit rate control	Constant Bit Rate (CBR)
Total megapixels	5 MP
Gain control type	Auto
Maximum resolution	2560 x 1920 pixels
Video formats supported	H.264, H.265
Analog signal format system	NTSC, PAL
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 960, 1600 x 1200 (UXGA), 2048 x 1536 (QXGA), 2560 x 1920
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	256 GB
Sensor type	CMOS
Optical sensor size	1/2.7 \
White balance	Auto, Manual
Minimum illumination	0.03 lx
IK code	IK10
Form factor	Spherical
Mounting type	Ceiling/wall
Product color	Black, White
Country of origin	Taiwan
International Protection (IP) code	IP66
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired & Wireless
Maximum operating distance	30 m

Weight and Dimensions

Depth	99.8 mm
Width	133.3 mm
Weight	760 g
Package weight	1100 g
