Configuring Network Settings
53
Enter the information of Country, State or province, Locality, Organization and Organization
unit. Click Create. The following figure is displayed:
Figure 5-15 Certificate Request Created
Click Export to export the certificate request to your local computer. After you get the signing
certificate from the certificate issuing authority, click Browse and Upload to import it to the
camera. The imported certificate will replace the original self-signed certificate of the camera.
After the certificate file is uploaded successfully, if you want to remove the certificate, click
Remove.
Upload files
Go to Setup Network Setup HTTPS Upload files.
You can import the certificate from third party here.
Figure 5-16 Upload files
To import the certificate from third party:
1. In the Certificate field, click Browse to select a certificate file you have already applied
from 3rd party or CA domain.
2. In the Key field, click Browse to select a certificate key you have already applied from 3rd
party or CA domain.
3. Click Upload and reboot camera.
After the certificate file is uploaded successfully, if you want to remove the certificate, click
Remove.
Note
Supported certificate type: HTTPS protocol.
Supported certificate file format: *.cert format.
Supported Key format: PEM format.

Table of Contents

Other manuals for Honeywell HC30W45R2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Honeywell HC30W45R2 and is the answer not in the manual?

Honeywell HC30W45R2 Specifications

General IconGeneral
Windows operating systems supportedWindows 10, Windows 7
DC-in jackYes
Ethernet LAN (RJ-45) ports1
Lens diameter2.8 mm
Fixed focal length2 mm
Maximum aperture number2
DC output voltage12
Power source typeDC, PoE
Power consumption (max)12.95 W
Operating temperature (T-T)-30 - 60 °C
Operating relative humidity (H-H)0 - 90 %
Wi-FiNo
Number of users10 user(s)
Ethernet interface typeGigabit Ethernet
Bit rate controlConstant Bit Rate (CBR)
Total megapixels5 MP
Gain control typeAuto
Maximum resolution2560 x 1920 pixels
Video formats supportedH.264, H.265
Analog signal format systemNTSC, PAL
Supported graphics resolutions640 x 480 (VGA), 800 x 600 (SVGA), 1280 x 960, 1600 x 1200 (UXGA), 2048 x 1536 (QXGA), 2560 x 1920
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size256 GB
Sensor typeCMOS
Optical sensor size1/2.7 \
White balanceAuto, Manual
Minimum illumination0.03 lx
IK codeIK10
Form factorSpherical
Mounting typeCeiling/wall
Product colorBlack, White
Country of originTaiwan
International Protection (IP) codeIP66
TypeIP security camera
Placement supportedIndoor & outdoor
Connectivity technologyWired & Wireless
Maximum operating distance30 m
Weight and Dimensions IconWeight and Dimensions
Depth99.8 mm
Width133.3 mm
Weight760 g
Package weight1100 g
