Installation
______________________________________________________________________________________________
26
Connection Guide
Connecting the Monitor
There are three available monitor outputs on the DVR.
• Composite Monitor output for CCTV monitor – BNC (Marked MAIN)
• Spot monitor output for CCTV monitor - BNC (Marked SPOT)
• VGA output for VGA monitor – Mini-Sub D15
Video Inputs and Looping Outputs
The HRDP DVR comes with 4/8/16 BNC video inputs on the rear of its
chassis. Each video input has a corresponding looping BNC output for
passing the video signal to another monitoring/recording device.
Connecting to a Network
Use the RJ45 jack on the rear of the DVR when connecting to a network.
Connecting Audio
To record audio on the DVR connect the audio source to the connections on
the audio ports on the back of the DVR.
To listen to live or recorded audio connect the Audio Out Port to an amplified
speaker system.
Note The DVR audio output is a line level source which requires an
amplified speaker system. The audio input can be from an amplified
source or line level microphone.
