Page #109 background imageLoading...
Page #109 background image
HRDP DVR User Guide
______________________________________________________________________________________________
Document 800-06801 Rev D 109
02/11
Specifications (HRDPX H.264)
Specification
16 Channel
Video
Inputs
16 Channel Composite
Outputs
CCTV Monitor (NTSC/PAL),
CRT(VGA) Monitor
16 CH Looping Composite
3 Spot CCTV Monitor (NTSC/PAL)
Monitoring
Display
NTSC : 480 fps
PAL : 400 fps
Screen split
1/4/9/16/PIP
Recording
Performance
NTSC: CIF(480 ips), 2CIF (240 ips), 4CIF (120 ips)
PAL: CIF (400 ips), 2CIF(200 ips), 4CIF (100 ips)
Resolution
NTSC: CIF(352x240), 2CIF(704x240), 4CIF (704x480)
PAL: CIF(352x288), 2CIF (704x288), 4CIF(704x576)
Compression
H.264
Mode
Motion detection, Sensor, Schedule
Variable compression rates, recording frame, motion sensitivity
Recording
Storage media
Internal 2 x HDD (Option) USB
Audio
4 Channel, G.726 Compression
Playback
Mode
Multi-channel playback (Max 16ch), Simultaneous playback
Searching
By Channel, Time, Date, Motion Detection, Sensor Events
Remote Monitoring S/W
Remote Software / Web based viewer
Alarm
4
Sensor
16
Camera Control
Pan/Tilt, Zoom, Focus, Iris
Back-up
DVD+/-RW USB
Hardware
Spec.
Size
15.75" (W) x 3.46" (H) x 15.75" (D) (400 mm x 88 mm x 400 mm)
Weight
18 lb (8.2 kg) W/O Packing
Power
Input Voltage is 12V DC
UPS
External UPS recommended
