ID2000 Series Installation & Commissioning Manual
Contents
iv997-433-000-5, Issue 5
May 2010
8.3 Powering the Panel 42
8.4 External Wiring 42
8.4.1 Introduction 42
8.4.2 Loop Checks Before Connecting Wiring 43
8.4.3 Connecting the Loop Wiring to the Panel 44
8.4.4 Loop Checks After Connecting Wiring 44
8.4.5 24V Auxiliary Outputs Check 45
8.4.6 Sounder Circuits Check 45
8.4.7 Fault Relay Wiring 45
8.5 Batteries 46
8.5.1 Connecting the Batteries 46
8.5.2 Battery Disposal 47
8.6 Earth Fault Monitoring 47
8.7 Volt-free Contact Output Option 48
8.8 Repeaters 48
8.9 Configuration and Handover 48
8.10 System Test 48
8.10.1 Zone Walk Test 48
8.10.2 Control Output Test 48
9 Maintenance 47
9.1 Routine Testing 47
9.2 Batteries 47
9.3 Cleaning 47
Appendices:
Appendix 1 Fault Messages and
Possible Meanings A1-1 to A1-5
Appendix 2 Specifications A2-1 to A2-5
Appendix 3 ID2000 System
Design Guide A3-1 to A3-3
