Page 8 IFS-2600 Installation & Programming Manual
P/N 10069 ECN08-0066
SYSTEM EXPANSION
Zones Qty Hardware Required Product Code
8 1 Main Control Board PCB-2004
1 Main Termination board PCB-2005
1 Power Supply board PCB-2006
16 1 Main Control board PCB-2004
1 Main Termination board PCB-2005
1 Power Supply board PCB-2006
1 8 Zone Expansion board PCB-804G3
1 16 Zone Indicator board PCB-816
24 1 Main Control board PCB-2004
1 Main Termination board PCB-2005
1 Power Supply board PCB-2006
2 8 Zone Expansion board PCB-804G3
1 16 Zone Indicator board PCB-816
32 1 Main Control board PCB-2004
1 Main Termination board PCB-2005
1 Power Supply board PCB-2006
3 8 Zone Expansion board PCB-804G3
2 16 Zone Indicator board PCB-816
40 1 Main Control board PCB-2004
1 Main Termination board PCB-2005
1 Power Supply board PCB-2006
4 8 Zone Expansion board PCB-804G3
2 16 Zone Indicator board PCB-816
48 1 Main Control board PCB-2004
1 Main Termination board PCB-2005
1 Power Supply board PCB-2006
5 8 Zone Expansion board PCB-804G3
3 16 Zone Indicator board PCB-816
56 1 Main Control board PCB-2004
1 Main Termination board PCB-2005
1 Power Supply board PCB-2006
6 8 Zone Expansion board PCB-804G3
3 16 Zone Indicator board PCB-816
64 1 Main Control board PCB-2004
1 Main Termination board PCB-2005
1 Power Supply board PCB-2006
7 8 Zone Expansion board PCB-804G3
4 16 Zone Indicator board PCB-816
Additional relay outputs:
Relays Qty Hardware Required Product Code
8 1 Relay board containing 8 relays 24VDC 1A IFS-717
16 2 Relay board containing 8 relays 24VDC 1A IFS-717
24 3 Relay board containing 8 relays 24VDC 1A IFS-717
32 4 Relay board containing 8 relays 24VDC 1A IFS-717
40 5 Relay board containing 8 relays 24VDC 1A IFS-717
48 6 Relay board containing 8 relays 24VDC 1A IFS-717
56 7 Relay board containing 8 relays 24VDC 1A IFS-717
64 8 Relay board containing 8 relays 24VDC 1A IFS-717
