Page 30 IFS-2600 Installation & Programming Manual
P/N 10069 ECN08-0066
RELAYS
TYPE MAPPING
ISOLATE RELAY
ANCILLARY OUTPUT (ACF)
BRIGADE RELAY #1
BRIGADE RELAY #2
FAULT RELAY
MAINS FAIL RELAY
GENERAL ALARM RELAY
BELL OUTPUT
DOOR HOLDER RELAY
MAP - AND (00)(00)(00)(00)(00)
MAP - OR (00)(00)(00)(00)(00)
MAP - FAULT (00)(00)(00)(00)(00)
MAP – ISOLATE (00)(00)(00)(00)(00)
MAP – ISOLATE / FAULT (00)(00)(00)(00)(00)
DOOR SWITCH
RESET
GLOBAL
ACF AVF RELAY TIME
NON-LATCHING ND DISABLED MAP RELAY (XX) >>> (DD) / (MM) / (YY)
LATCHING ND 2 MINUTES FROM ZONE XX (HH) : (MM)
NON-LATCHING NE 3 MINUTES
LATCHING NE 4 MINUTES
5 MINUTES
ND: = NORMALLY DE-ENERGISED
NE: = NORMALLY ENERGISED
PRINT
PRINT
PRINTS OUT CURRENT CONFIGURATION
MAIN MENU
(ZONES) RELAYS
GLOBAL PRINT
Use the "NEXT" & "PREVIOUS" keys to scroll through "ZONES" "RELAYS" "GLOBAL" "PRINT" and wrap
around. Once the desired option has been highlighted, pressing the "SELECT" button will select it.
Pressing "EXIT" at this stage will exit programming mode.
