Page 20 IFS-2600 Installation & Programming Manual
P/N 10069 ECN08-0066
INSTRUCTIONS TO OPERATORS
INDICATORS
Qty Descriptor Colour Function Buzzer
1 MAINS ON Green Illuminates when there is 200/220/240 VAC supply to
the panel.
1 BATTERY
FAULT
Yellow Illuminates if the battery fails a battery test.
Illuminates if batteries are disconnected >30
seconds.
Illuminates if batteries are short circuit >30 seconds.
Yes
1 PSU FAULT Yellow Illuminates if the power supply is outside the
manufacturers range.
Yes
1 CHARGER
LOW
Yellow Illuminates if the battery charger is outside the
recommended float charge voltage.
Yes
1 COMMON
FAULT
Yellow Illuminates if;
Any un-isolated zone goes into fault.
ACF output is open or short circuit
Bell output is open or short circuit
Warning System output is open or short circuit
Battery Fault
Charger Fault
Power Supply Fault
MAF Isolate Input is Open Circuit
Configuration Fault
Yes
1 ACF ACT Red Illuminates if the ACF output has been activated.
1 ACF FLT Yellow Illuminates if the ancillary circuit is open or short
circuit. The LED will extinguish when the load is
restored.
Yes
1 ACF ISO Yellow Illuminates if the ancillary output has been manually
isolated.
1 Bell ACT Red Illuminates when the bell output has been energised.
1 Bell FLT Yellow Illuminates if the bell circuit is open or short circuit.
The LED will extinguish when the load is restored.
Yes
1 Bell ISO Yellow Illuminates if the bell output has been manually
isolated.
1 Warning
System ACT
Red Illuminates if the Warning System output has been
energised.
1 Warning
System FLT
Yellow Illuminates if the Warning System circuit is open or
short circuit. The LED will extinguish if the load is
restored.
Yes
1 Warning
System ISO
Yellow Illuminates if the Warning System has been manually
isolated.
8 ALARM LEDS Red This LED will flash if it's corresponding zone goes
into alarm. It will remain flashing until it is
Acknowledged at which time it will go steady and
remain on until the alarm is reset. If the zone is
programmed as a time delay type, a steady LED
indicates the “pre-alarm” condition. If the zone is
isolated and in alarm it will also be steady.
Yes
8 FAULT LEDS Yellow This LED illuminates if it's corresponding zone goes
into fault. It will remain on until the fault is removed.
Yes
8 ISOLATE LEDS Yellow This LED illuminates if its corresponding zone is
isolated. It will remain on until the zone is de-
isolated.
To Next Page
