Page 28 IFS-2600 Installation & Programming Manual
P/N 10069 ECN08-0066
OUTPUT RELAY OPTIONS
Optional Relays can be programmed to simulate: -
 Isolate Relay
 ACF Output
 Brigade Relay #1
 Brigade Relay #2
 Fault Relay
 Mains Fail Relay
 General Alarm Relay
 Bell Output
 Door Holder Relay
 Door Switch
 Reset
Or Can Be Used To:
 "MAP AND" Up to 5 Zones in Alarm
 "MAP OR" Up to 5 Zones in Alarm
 “MAP FAULT” Up to 5 Zones in Fault
 “MAP ISOLATE” Up to 5 Zones in Isolate
 “MAP ISO/FAULT” Up to 5 Zones in Isolate/Fault
DEFAULT SETTINGS
ACF OUTPUT NON-LATCHING, NORMALLY DE-ENERGISED
ALARM VERIFICATION (AVF) 3 MINUTES
TIME 1/1/11 11:11
ZONE TYPES STANDARD LATCH 2S
ZONE OUTPUT CONFIG I-B-G-A-BR1 & BR2
RELAY MAPPING MAP -OR-, MAPPING = 1 TO 1
IE: RELAY 1 = ZONE 1, RELAY 2 = ZONE 2.............
The 2600 PANEL is self-configuring on power-up therefore it is not necessary to program the number
of relay boards.
Zone expansion boards fitted must have the correct jumper selected.
