10 NCD Instruction Manual — P/N LS10210-051NF-E:C 2/18/2019
About this Manual Technical Specifications
Display Conditioning
Every 30 minutes the display will enter Display conditioning mode. During Display Conditioning the display will transition through var-
ious screens including a completely blank screen. This process takes about seven seconds. It is done to prevent image persistence, and
keeps information clear and undistorted. Any display interaction will abort Display Conditioning mode. Display conditioning mode will
not activate if there are active alarm conditions.
1.9 Technical Specifications
Power Input: 24VDC.
USB Ports:
USB is 2.0, USB A and USB Micro are located on the Core Board, USB C is located on the front of the NCD display.
Touch Screen Display: 10 inch High Definition Touch Screen Display.
Current draw: 360mA in Standby. 380mA in Alarm.
Tamper and Trouble Input: Tamper and Trouble inputs.
Trouble Relay: 30VDC 2A
NOTE: Display Conditioning mode is not configurable.
