100 RP-2002 Series Manual — P/N 53039:E6 1/26/2017
Appendix B: FACP Configuration Templates
The RP-2002 has been provided with preprogrammed templates which allows the user to quickly
configure the FACP [refer to “FACP CONFIG (Application Templates)” on page 53]. The user also
has the option to reprogram selected portions of each template for customized applications. The fol-
lowing pages of this appendix describe the programming for the templates.
Important! The Templates have been programmed with specific Input Zone Types and Output
Circuit Types. If the FACP is configured with the preprogrammed Templates, the user must ensure
that the devices connected to each Input Zone and Output Circuit are compatible with the pro-
grammed types. (The user can reprogram the circuit types if desired).
NOTE: The RP-2002 Agent Release Control Panel can be configured using preprogrammed
Templates 1 through 13.
