RP-2002 Series Manual — P/N 53039:E6 1/26/2017 125
Template 9: Dual Hazard - Cross-Zone FACP Configuration Templates
B.9 Template 9: Dual Hazard - Cross-Zone
Table Legend:
X = direct correlation between Input Zone and Output Circuit (input zone activation will turn on
corresponding output circuit after any applicable delays).
Xc = cross-zone output where X indicates a direct correlation between Input Zone and Output Cir-
cuit (input zone activation will activate the corresponding output circuit) and c indicates that the
output circuit will indicate when one or more inputs of a cross-zoned group have been activated
(refer to “Cross-Zone for Release Circuit 1 or Release Circuit 2:” on page 61).
Cn = cross-zone inputs where n is the number of the Release Circuit. All inputs with the same
Release Circuit number must be active at the same time to turn on the corresponding Release output
circuit.
Input Zone Types:
• Zone 1 = circuit with type code of 2-wire smoke
• Zone 2 = circuit with type code of 2-wire smoke
• Zone 3 = circuit with type code Manual Release/Abort Switch Combination - activation of the
Manual Release will cause an immediate agent release; Abort Switch - programmed for UL
Abort Type operation (refer to “Abort Type” on page 65)
• Zone 4 = circuit with type code of 2-wire smoke
• Zone 5 = circuit with type code of 2-wire smoke
• Zone 6 = circuit with type code Manual Release/Abort Switch Combination - activation of the
Manual Release will cause an immediate agent release; Abort Switch - programmed for UL
Abort Type operation (refer to “Abort Type” on page 65)
Output Circuit Types:
• Output 1 = Release Circuit 1 - Supervised for shorts
• Output 2 = Release Circuit 2 - Supervised for shorts
• Output 3 = Horn NAC - silenceable, programmed Cross-Zone coding operation for Release
Circuit 1 (refer to “Cross-Zone for Release Circuit 1 or Release Circuit 2:” on page 61)
• Output 4 = Horn NAC - silenceable, programmed Cross-Zone coding operation for Release
Circuit 2 (refer to “Cross-Zone for Release Circuit 1 or Release Circuit 2:” on page 61)
Timers
• Pre-Discharge Delay: Release 1 - set for 30 seconds; Release 2 - set for 30 seconds
• Discharge: Release 1 - set for Always On; Release 2 - set for Always On
• Waterflow Delay Timer - set for 90 seconds
• AC Loss Delay Timer - set for 2 hours
Template 9: Dual Hazard - Cross-Zone
INPUT ZONES
12 3 45 6
OUTPUT CIRCUITS
2-WIRE
SMOKE
2-WIRE
SMOKE
MANUAL
RELEASE/ABORT
SW. COMBO
2-WIRE
SMOKE
2-WIRE
SMOKE
MANUAL
RELEASE/ABORT
SW. COMBO
#1 RELEASE CIRCUIT 1
C1 C1 X
#2 RELEASE CIRCUIT 2
C2 C2 X
#3 HORN NAC
Xc Xc X
#4 HORN NAC
Xc Xc X
To Next Page
