Template 11: Agent/Waterflow - Cross-Zone FACP Configuration Templates
B.11 Template 11: Agent/Waterflow - Cross-Zone
Table Legend:
* = shows relationship only, will not activate a release circuit
X = direct correlation between Input Zone and Output Circuit (input zone activation will turn on
corresponding output circuit after any applicable delays).
Xc = cross-zone output where X indicates a direct correlation between Input Zone and Output Cir-
cuit (input zone activation will activate the corresponding output circuit) and c indicates that the
output circuit will indicate when one or more inputs of a cross-zoned group have been activated
(refer to Cross Zone in “Cross-Zone for Release Circuit 1 or Release Circuit 2:” on page 61).
Cn = cross-zone inputs where n is the number of the Release Circuit. All inputs with the same
Release Circuit number must be active at the same time to turn on the corresponding Release output
circuit.
Xr = release stage output where X indicates a direct correlation between Input Zone and Output
Circuit (input zone activation will activate the corresponding output circuit) and r indicates that the
output circuit will indicate one of three stages of a releasing operation by its pulse rate (refer to
“Release Stage/NAC Operation” on page 85).
Input Zone Types:
• Zone 1 = circuit with type code of 2-wire smoke
• Zone 2 = circuit with type code of 2-wire smoke
• Zone 3 = circuit with type code Manual Release/Abort Switch Combo - activation of the
Manual Release will cause an immediate agent release; Abort Switch - programmed for UL
Abort Type operation (refer to “Abort Type” on page 65)
• Zone 4 = circuit with type code of Discharge Pressure Switch
• Zone 5 = circuit with type code of Waterflow
• Zone 6 = circuit with type code of Supervisory
Output Circuit Types:
• Output 1 = Release Circuit 1 - Supervised for shorts
• Output 2 = Release Circuit 2 - Supervised for shorts
• Output 3 = Alarm NAC - silenceable, programmed for Cross-Zone Pre-Discharge coded
operation for Release Circuit 1 (refer to “Cross-Zone for Release Circuit 1 or Release Circuit
2:” on page 61)
• Output 4 = Release Stage Coded - nonsilenceable, programmed Release Stage Coded operation
for Release Circuit 1 (refer to “Cross-Zone for Release Circuit 1 or Release Circuit 2:” on
page 61)
Template 11: Agent/Waterflow - Cross-Zone
INPUT ZONES
12 3 4 5 6
OUTPUT CIRCUITS
2-WIRE
SMOKE
2-WIRE
SMOKE
MANUAL
RELEASE/ABORT
SW. COMBO
DISCHARGE
PRESSURE
WATERFLOW SUPERVISORY
#1 RELEASE CIRCUIT 1
C1 C1 X X*
#2 RELEASE CIRCUIT 2
C2 C2 X X*
#3 ALARM NAC
Xc Xc X X
#4 RELEASE STAGE
CODED
Xr Xr Xr Xr
