FACP Configuration Templates Template 12: Agent/Waterflow - Single Detector
B.12 Template 12: Agent/Waterflow - Single Detector
Table Legend:
* = shows relationship only, will not activate a release circuit
X = direct correlation between Input Zone and Output Circuit (input zone activation will turn on
corresponding output circuit after any applicable delays).
Xr = release stage output where X indicates a direct correlation between Input Zone and Output
Circuit (input zone activation will activate the corresponding output circuit) and r indicates that the
output circuit will indicate one of three stages of a releasing operation by its pulse rate (refer to
“Release Stage/NAC Operation” on page 85).
Input Zone Types:
• Zone 1 = circuit with type code of 2-wire smoke
• Zone 2 = circuit with type code of 2-wire smoke
• Zone 3 = circuit with type code Manual Release/Abort Switch Combo - activation of the
Manual Release will cause an immediate agent release; Abort Switch - programmed for UL
Abort Type operation (refer to “Abort Type” on page 65)
• Zone 4 = circuit with type code of Discharge Pressure Switch
• Zone 5 = circuit with type code of Waterflow
• Zone 6 = circuit with type code of Supervisory
Output Circuit Types:
• Output 1 = Release Circuit 1 - Supervised for shorts
• Output 2 = Release Circuit 2 - Supervised for shorts
• Output 3 = Alarm NAC - silenceable, steady on
• Output 4 = Release Stage Coded - nonsilenceable, programmed Release Stage Coded operation
for Release Circuit 1 (refer to“Cross-Zone for Release Circuit 1 or Release Circuit 2:” on
page 61)
ANN-BUS
• Enabled = Yes
• Address 1: ANN-RLY
Timers
• Pre-Discharge Delay: Release 1 - set for 30 seconds; Release 2 - set for 0 seconds
• Discharge: Release 1 - set for Always On; Release 2 - set for Always On
• Waterflow Delay Timer - set for 90 seconds
• AC Loss Delay Timer - set for 2 hours
Template 12: Agent/Waterflow - Single Detector
INPUT ZONES
12 3 4 5 6
OUTPUT CIRCUITS
2-WIRE
SMOKE
2-WIRE
SMOKE
MANUAL
RELEASE/AB
ORT SW.
COMBO
DISCHARGE
PRESSURE
WATERFLOW SUPERVISORY
#1 RELEASE CIRCUIT 1
XX X X*
#2 RELEASE CIRCUIT 2
XX X X*
#3 ALARM NAC
XX X X X
#4 RELEASE STAGE
CODED
Xr Xr Xr Xr
