96 RP-2002 Series Manual — P/N 53039:E6 1/26/2017
Circuit Mapping and Cross-Zoning Input-to-Output Circuit Mapping and Cross-Zone Operation
A.1.1 Mapping Input Zones to Output Circuits for Direct Activation
Using the INPUT ZONES menus, you can assign any input zone to directly activate (without cross-
zoning) any of the four output circuits provided they are assigned matching operational types (see
the OUTPUT CIRCUIT MAP menu within the INPUT ZONES menus).
Example 1: A waterflow input zone assigned to directly activate an alarm output circuit by setting
the OUTPUT CIRCUIT MAP assignment to YES.
Output Circuit 1 is programmed as alarm NAC using the OUTPUT CIRCUITS menus.
Output Circuit 2 is programmed as Release Circuit 1 using the OUTPUT CIRCUITS menus.
Output Circuit 3 is programmed as Release Circuit 2 using the OUTPUT CIRCUITS menus.
Output Circuit 4 is programmed as supervisory NAC using the OUTPUT CIRCUITS menus.
Input Zone 1 is programmed as a waterflow zone using the INPUT ZONES menus.
Waterflow Input Zone 1 will directly activate Output Circuit 1 (Alarm NAC) but not Output
Circuits 2, 3 or 4.
Example 2: A single hazard application where a smoke detector input zone will directly activate
both an alarm NAC circuit and a releasing output circuit.
Output Circuit 1 is programmed as alarm NAC using the OUTPUT CIRCUITS menus.
Output Circuit 2 is programmed as Release Circuit 1 using the OUTPUT CIRCUITS menus.
Output Circuit 3 is programmed as waterflow NAC using the OUTPUT CIRCUITS menus.
Output Circuit 4 is programmed as supervisory NAC using the OUTPUT CIRCUITS menus.
Input Zone 1 is programmed as a smoke detector zone using the INPUT ZONES menus.
Smoke detector Input Zone 1 will directly activate Output Circuits 1 (Alarm NAC) and 2 (Release
1) but not output circuits 3 or 4.
ZONE 1 TYPE
1=N/A
2=N/A
3=WATERFLOW
OUTPUT MAP ZONE 1
1=ALARM NAC YES
2=RELEASE 1 NO
3=RELEASE 2 NO
OUTPUT MAP ZONE 1
1=SUPV BELL NAC N/A
ZONE 1 TYPE
1=2-WIRE SMOKE
2=2-WIRE HEAT
3=N/A
OUTPUT MAP ZONE 1
1=ALARM NAC YES
2=RELEASE 1 YES
3=WATERFLOW NAC NO
OUTPUT MAP ZONE 1
1=SUPV BELL NAC N/A
