104 RP-2002 Series Manual — P/N 53039:E6 1/26/2017
FACP Configuration Templates Template 2: Single Zone System With Horn
B.2 Template 2: Single Zone System With Horn
Table Legend:
X = direct correlation between Input Zone and Output Circuit (input zone activation will turn on
corresponding output circuit after any applicable delays).
Xr = release stage output where X indicates a direct correlation between Input Zone and Output
Circuit (input zone activation will activate the corresponding output circuit) and r indicates that the
output circuit will indicate one of three stages of a releasing operation by its pulse rate (refer to
“Release Stage/NAC Operation” on page 85).
Input Zone Types:
• Zone 1 = circuit with type code of 2-wire smoke
• Zone 2 = circuit with type code of 2-wire smoke
• Zone 3 = circuit with type code Manual Release - activation will cause an immediate agent
release
• Zone 4 = circuit with type code of Abort Release Switch - programmed for UL Abort Type
operation (refer to “Abort Type” on page 65)
• Zone 5 = circuit with type code of Pull Station
• Zone 6 = circuit with type code of Supervisory
Output Circuit Types:
• Output 1 = Release Circuit 1 - Unsupervised for shorts
• Output 2 = Release Stage NAC - silenceable, programmed Release Stage operation (refer to
“Release Stage/NAC Operation” on page 85)
• Output 3 = Alarm NAC - silenceable, coded for steady on
• Output 4 = Alarm NAC - silenceable, coded for steady on
Timers
• Pre-Discharge Delay - set for 30 seconds
• Discharge - set for 1 minute
• Waterflow Delay Timer - set for 90 seconds
• AC Loss Delay Timer - set for 2 hours
Template 2: Single Zone System with Horn
INPUT ZONES
12 345 6
OUTPUT CIRCUITS
2-WIRE
SMOKE
2-WIRE
SMOKE
MANUAL
RELEASE
ABORT PULL
STATION
SUPERVISORY
#1 RELEASE CIRCUIT 1
XX X X
#2 RELEASE STAGE NAC
Xr Xr Xr
#3 ALARM NAC
X
#4 ALARM NAC
XX X
