Appendix A - Central Station Reporting Formats
A-5
For some reporting codes, the first of the two programmable digits determines the PID Event code to be
transmitted. Other reporting codes transmit a dedicated PID Event code regardless of the digit
programmed in the first location. In both cases, if transmissions are not desired, program AA in
Locations 1 and 2. Refer to the following tables to select the PID Event codes to be transmitted.
BURGLARY ZONE TYPES
Digit EVENT
CODE
ENGLISH OUTPUT AT CS
RECEIVER
0 122 Silent Panic
1 123 Audible Panic
2 130 Burglary
3 131 Perimeter
4 132 Interior
5 133 24-Hour Alarm
6 134 Entry/Exit
7 135 Day/Night
8 136 Outdoor
9 137 Tamper
A 140 General Alarm
B 144 Sensor Tamper
C 155 Poll Break
D 156 Day Trouble
24-HOUR ALARM TYPES
Digit EVENT
CODE
ENGLISH OUTPUT AT CS
RECEIVER
0 100 Medical
1 101 Pendant Transmitter
2 120 Panic Alarm
3 122 Silent Alarm
4 123 Audible Alarm
5 130 Burglary
6 133 24-Hour Alarm
7 135 Day/Night
8 137 Tamper
9 140 General Alarm
A 150 24-Hour Non-Burglary
B 151 Gas Detected
C 152 Refrigeration
D 153 Loss of Heat
E 154 Water Leakage
F 155 Foil Break
FIRE ZONE TYPES
Digit EVENT
CODE
ENGLISH OUTPUT AT CS
RECEIVER
0 110 Fire Alarm
1 111 Smoke
2 112 Combustion
3 113 Water Flow
4 114 Heat
5 115 Pull Station
6 116 Duct
7 117 Flame
8 140 General Alarm
9 150 24-Hour Non-Burglary
A 158 High Temperature
B 159 Low Temperature
C 200 Fire Supervisory
D 201 Low H2O Pressure
E 202 Low CO2
F 203 Gate Valve Sensor
24-HOUR TROUBLE TYPES
Digit EVENT
CODE
ENGLISH OUTPUT AT CS
RECEIVER
0 100 Medical
1 122 Silent Panic
2 123 Audible Panic
3 137 Tamper
4 150 24-Hour Non-Burglary
5 153 Loss of Heat
6 155 Foil Break
7 156 Day Trouble
8 158 High Temperature
9 159 Low Temperature
A 300 System Trouble
B 301 AC Loss
C 302 Low System Battery
D 310 Ground Fault
E 373 Fire Trouble
F 380 Sensor Trouble
