Section 4 – System Operations
4–5
Keypad Backlight Timer
The OMNI-KP, OMNI-KP-US, OMNI-LCD, and OMNI-LCD-US keypads have a timer controlled
keypad backlight that is on for 120-seconds following a key press (timer on) or constantly on (timer off).
Enabling backlight timer:
OMNI-KP and OMNI-KP-US: Press the INSTANT and CODE keys at the same time and hold down for
two seconds until you hear a beep. Pressing the [1] key toggles a zero or one in the display.
0 = Timer off (backlight always on)
1 = Timer on (backlight on for 120-seconds following key press)
Press the [✱] key to exit this Backlight menu.
OMNI-LCD and OMNI-LCD-US: Press and hold down the INSTANT and CODE keys at the same time
for about two seconds. Press the [1] key to toggle the display between:
Backlight 120s time out
and
Backlight Always On
Press [✱] key to exit this Backlight menu.
Keypad Addressing
This address will identify the keypad number to the control panel. A maximum of 4 keypads (OMNI-
KP, OMNI-KP-US, OMNI-LCD, OMNI-LCD-US, or XK7LC, or XK108) can be identified.
When the XK108 is used, keypad addressing does not apply. Additionally, you cannot use any
other type of keypad if you are using XK108’s on the system.
Set the OMNI-KP, OMNI-KP-US, OMNI-LCD, and OMNI-LCD-US keypad addresses by doing the
following (refer to the instructions provided with the keypads for additional information on setting the
keypad addresses):
1. Within 30 seconds of applying power to the unit, press the [CODE] and [STAY] keys at the same
time and hold them for several seconds.
2. When the display shows a single digit pulsing, enter the address 1–8 for fixed-word and for LCD
keypads.
3. To terminate the mode, press [✱].
Set the XK7LC keypad address by using its DIP switches. Refer to the instructions provided with the
keypad for additional information on setting the keypad address.
NOTE: When the programming mode is ended or the next time the system is powered up, the keypads
will be recognized by the panel.
Arming the System
The system can be armed only if all burglary zones are in ready state (not faulted):
Indicator OMNI-LCD/OMNI-LCD-US/XK7LC OMNI-KP/OMNI-KP-US XK108
LED Lit Ready Ready Ready
Display SYSTEM READY n/a n/a
