OMNI-408/OMNI-408EU Installation and Setup Guide
B–4
RF Mode Programming
TO ENTER RF PROGRAMMING:
Press [*] [#] 2-digit Question Number; or [BYPASS]
2-digit Question Number
Question LEDs pulse in RF programming mode.
NOTE: If RF Receiver Board is not available, RF
Programming can not be modified.
TO SKIP A QUESTION:
Press [*] 2-digit Question Number
TO MOVE WITHIN A QUESTION:
Press [#] until the desired location is reached.
TO ENTER DATA:
single digit: 0 - 9, A - F [#]
A = [CODE] [1] D = [CODE] [4]
B = [CODE] [2] E = [CODE] [5]
C = [CODE] [3] F = [CODE] [6]
TO EXIT RF PROGRAMMING:
Press [STAY]
Questions 01-14, L1 - RF Device Options
Digit Option Explanation
0 DISABLED NOT APPLICABLE
1 1 Zone or Button Only 1 Zone or 1 Button
2 2 Zones or Buttons 2 Consecutive Zones or 2
Buttons
3 3 Zones or Buttons 3 Consecutive Zones or 3
Buttons
4 4 Buttons 4 Buttons (Keyfobs)
Questions 01-14, L2 - RF Device Type
Digit Type Explanation
0 DISABLED NOT APPLICABLE
1 5800 Transmitter 5800 Series Transmitters
(Select for Keyfobs)
9 5816 Transmitter 5816 Transmitter using
magnetic relay only
Questions 01-14, L3 through L9 - 5800 Serial Number
Enter the 7-digit serial number printed on the device for all
5800 RF devices to be used.
01 RF DEVICE 1 DEFINITION Default: 000000000 02 RF DEVICE 2 DEFINITION Default: 000000000
1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9
OPT TYPE SERIAL NUMBER OPT TYPE SERIAL NUMBER
03 RF DEVICE 3 DEFINITION Default: 000000000 04 RF DEVICE 4 DEFINITION Default: 000000000
1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9
OPT TYPE SERIAL NUMBER OPT TYPE SERIAL NUMBER
05 RF DEVICE 5 DEFINITION Default: 000000000 06 RF DEVICE 6 DEFINITION Default: 000000000
1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9
OPT TYPE SERIAL NUMBER OPT TYPE SERIAL NUMBER
07 RF DEVICE 7 DEFINITION Default: 000000000 08 RF DEVICE 8 DEFINITION Default: 000000000
1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9
OPT TYPE SERIAL NUMBER OPT TYPE SERIAL NUMBER
09 RF KEYFOB 1 DEFINITION Default: 000000000 10 RF KEYFOB 2 DEFINITION Default: 000000000
1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9
OPT TYPE SERIAL NUMBER OPT TYPE SERIAL NUMBER
11 RF KEYFOB 3 DEFINITION Default: 000000000 12 RF KEYFOB 4 DEFINITION Default: 000000000
1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9
OPT TYPE SERIAL NUMBER OPT TYPE SERIAL NUMBER
13 RF KEYFOB 5 DEFINITION Default: 000000000 14 RF KEYFOB 6 DEFINITION Default: 000000000
1 2 3 4 5 6 7 8 9 1 2 3 4 5 6 7 8 9
OPT TYPE SERIAL NUMBER OPT TYPE SERIAL NUMBER
