Appendix B — Default Settings
PC42t Desktop Printer User Guide 51
Media Length Sets the length of the printable area measured from
one edge of the label to the edge that is closest to the
printhead. Unit of measurement is defined in the Unit
of Measurement parameter.
1200 dots
Clip Default Determines if the printer prints items outside the
printable area of the label.
When this is set to Off, the printer returns an error if
any part of a bar code label cannot be printed
because that part extends beyond the printable area.
When this is set to On, the printer prints all bar code
labels, but may also print unreadable, incomplete
labels.
Off
Start Adjust Sets the length of media the printer feeds (positive
value) or retracts (negative value) before printing a
label. Unit of measurement is defined in the Unit of
Measure parameter. Range is -9999 to +9999.
0 dots
Stop Adjust Sets the length of media the printer feeds (positive
value) or retracts (negative value) after printing a
label. Unit of measurement is defined in the Unit of
Measure parameter. Range is -9999 to +9999.
0 dots
Media Calibration
Mode
Selects the mode the printer uses to calibrate media.
Use Slow if the printer has trouble identifying gaps or
marks in media
Fast
Media Settings (continued)
Setting Description Default

+RQH\ZHOO
2OG%DLOHV5RDG
)RUW0LOO6&
-EDIA
LENGTH

Honeywell PC42T Specifications

General

Color	No
Print technology	Thermal transfer
Maximum resolution	203 x 203 DPI
Maximum print height	- mm
Maximum printing width	104.1 mm
Certification	UL, cUL, cULus, CE, FCC, D Mark CCC, KCC, RCM
Internal memory	64 MB
Built-in barcodes	1D, 2D, Code 49, Data Matrix, EAN13, EAN8, MaxiCode, QR Code
Display	LED
Product color	Black
Ethernet LAN	Yes
Optional connectivity	Ethernet, Parallel, Serial (RS-232)
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ribbon width	109.2 mm
Core diameter	25.4 mm
Ribbon length	300 m
Maximum label width	110 mm
Maximum media length	9.6 mm
Maximum roll diameter	127 mm
Supported paper width	25.4 - 110 mm
Input current	1.5 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
AC adapter output current	2.5 A
AC adapter output voltage	24 V
Storage temperature (T-T)	-40 - 60 °C
Operating temperature (T-T)	5 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	297 mm
Width	226 mm
Height	177 mm
Weight	2500 g
