Table 3-7 Video Bit Stream Configurations

Parameter Function

Main Stream

Code-Stream Type Select from General stream and Motion stream. You can select different

encoder frame rates for different recording events.

The system supports the Active Control Frame (ACF) function. This allows

you to record in different frame rates.

For example, you can use a high frame rate to record important events, use

a lower frame rate to record scheduled events, and set a different frame rate

for recording motion detection.

Encode Mode Select from three options for Encoder Mode: H.264 (main profile standard),

H.264H (high profile standard), and MJPEG mode.

H.264: Main profile encoding mode.

H.264H: High profile encoding mode.

MJPEG: In this encoding mode, the video needs a larger bit stream to

guarantee the video definition. You can use the maximum bit stream value

in the Recommended Bit to get better video output.

Resolution You can select from multiple resolutions from the drop-down list. The

recommended bit stream value is different for each resolution.

Note You can not set a resolution higher than 720p (not including 720p)

when the Flip function is On.

Frame Rate (FPS) PAL: 1~25f/s; NTSC: 1~30f/s.

The frame rate can vary due to different resolutions.

Bit Rate Type Select either VBR or CBR.

Note You can set the video quality in VBR mode.

Reference Bit

Stream

Displays the Reference Bit Rate value according to the resolution and

frame rate you have selected.

Bit Rate In VBR, the Bit Rate here is the maximum value. In CBR, it is a fixed value.

See the Reference Bit Stream for a recommended value.

I Frame Interval Set the P-frame amount between two I frames. The value ranges from 25 to

150. The default is 50.

The recommended value for Frame Rate is *2.

Watermark This function allows you to verify that the video has not been altered. Select

to enable the Watermark function, and then enter the watermark text. The

default watermark text is DigitalCCTV. The maximum length is 85 digits.

The characters can include only numbers, letters, and an underline.
