Web Operation | 55
800-18161V1 - A - 07/2014
Snapshot
Figure 3-17 Snapshot Configuration Interface
Note See Path on page 57 for information about configuring where snapshots are
saved.
Note Snapshots are saved as JPEGs.
Table 3-8 Snapshot Configurations
Parameter Function
Shapshot Type Select from either General (schedule) or Event (activation).
Image Size Same as the main stream resolution.
Quality Select from six levels of image quality.
Interval Set the snapshot frequency from 1s to 7s.
