Honeywell ScanPal EDA5S User Manual

2 EDA5S Mobile Computer Series User Guide
EDA5S Model Overview
Note: To learn more, see Appendix A: Specifications beginning on page 87.
Available Features
Model
EDA5S-0
Model
EDA5S-1
Android operating system* x x
Qualcomm® SM6115, 2.0 GHz processor x x
Memory options are dependent on model and scan engine type.
• 3GB DDR4 RAM, 32 GB flash memory
• 4GB DDR4 RAM, 64 GB flash memory
• 6GB DDR4 RAM, 128 GB flash memory
xx
Choice of Honeywell high performance 2D imager x x
USB Type C connector for communication/charging/headset x x
High-tier rugged specifications with IP67sealing x x
WLAN IEEE 802.11 a/b/g/n/ac radio; Wi-Fi certified x x
Bluetooth™ V5.1 and Bluetooth Low Energy wireless technology
support
xx
NFC technology for short-range wireless data exchange x x
WWAN radio for high speed data and quality voice support across
all network technologies
x
Integrated GPS receiver; GPS protocol support for L1 bands that
include Simultaneous GNSS Receiver Support for GPS, GLONASS,
Galileo and Beidou, Assisted GPS
x
Customer-accessible microSD™ slot for removable memory cards
up to 128 GB (SDXC/SDHC/SDIO-compliant)
xx
13-megapixel color camera with video, image stabilization and
advanced software features for enhanced exposure control
xx
5-megapixel front-facing camera x x
Value-added software components supporting specialized
imaging and OCR functions
xx
Large, high definition (1440 x720) resolution, bright color,
outdoor-readable display with responsive multi-touch capacitive
touch panel**
xx
Integrated Ambient light sensor, proximity sensor, accelerometer,
hall sensor.
xx
* For information on supported Android OS versions, see the EDA5S Data Sheet, available at
sps.honeywell.com.
** Use of a screen protector may have a small effect on the capacitive touch panel performance.

Honeywell ScanPal EDA5S Specifications

General

Display diagonal	5.5 \
Touch technology	Multi-touch
Touchscreen type	Capacitive
Display resolution	1440 x 720 pixels
Internal memory	- GB
Internal memory type	-
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 90 %
Scanner type	1D/2D
Product color	Black, Grey
LED indicators	Battery level, Operation
International Protection (IP) code	IP67
Electrostatic Discharge (ESD) protection (air)	15 kV
Electrostatic Discharge (ESD) protection (contact)	8 kV
Antenna type	1x1
Data network	EDGE, GSM, HSPA+, LTE, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	5.1
Security algorithms	LEAP, PEAP, TLS, TTLS, WEP, WPA, WPA2, WPA2-Enterprise, WPA3, WPA3-Enterprise
Networking standards	IEEE 802.11d, IEEE 802.11e, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.11w
Number of cores	8
Processor family	Snapdragon
Processor frequency	2 GHz
Processor manufacturer	Qualcomm
Operating system installed	Android
Rear camera resolution (numeric)	13 MP
Front camera resolution (numeric)	5 MP
USB 2.0 ports quantity	1
Battery voltage	3.8 V
Battery capacity	3060 mAh
Battery life (max)	8 h
Battery recharge time (on)	3.5 h

Weight and Dimensions

Depth	11.2 mm
Width	75 mm
Height	159 mm
Weight	218 g
