Honeywell ScanPal EDA71 User Manual

EDA71 User Guide 37
Change the Scan Demo Symbology Settings
1. In the Scan Demo app, tap in the upper right corner of the screen.
2. Select Symbology Settings.
3. Modify the symbology parameters.
• Tap the check box next to a symbology name to enable (check mark) or
disable (no check mark) decoding for that symbology.
• Tap the symbology name to view and modify additional configuration
parameters for the symbology selected.
4. Tap Back to return to the Scan Demo app.
Use the Imager as a Flashlight
To use the imager as a flashlight.
1. Open Quick Settings (see page 38).
2. Tap the Flashlight icon to turn the flashlight on.
3. Select the icon again to turn the flashlight off.

Honeywell ScanPal EDA71 Specifications

General

Display diagonal	7 \
Display resolution	1280 x 720 pixels
Display technology	LCD
Processor cores	8
Processor model	SDM450
Processor family	Qualcomm Snapdragon
Processor frequency	1.8 GHz
Processor manufacturer	Qualcomm
Internal memory	2 GB
Internal memory type	-
Storage media	Flash
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size	128 GB
Internal storage capacity	32 GB
Number of built-in speakers	1
Rear camera type	Single camera
Rear camera resolution (numeric)	13 MP
WWAN	Installed
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
Mobile network connection	No
USB 2.0 ports quantity	4
Device type	Mobile tablet
Form factor	Slate
Product color	Black
International Protection (IP) code	IP64
Platform	Android
Operating system installed	Android 8.0
Battery capacity	- mAh
Battery life (max)	8 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	84713000

Weight and Dimensions

Depth	21 mm
Width	118 mm
Height	214 mm
Weight	- g
