Page #77 background image
9. Parts
8.8. Transmitter body
Revision 1 SmartLine Wireless Temperature and Universal I/O User's Manual 65
9. Parts
Individually saleable parts for the various transmitter models are listed in this section. Some parts
are illustrated for identification. Parts are identified and listed in the corresponding tables as
follows:
Individually saleable parts are indicated in each figure by key number callout.
Parts that are supplied in kits are indicated in each illustration by key number callout
with the letter K prefix.
8.8 Transmitter body
Table 9-1: Transmitter Body Parts
Part number Qty Description
50148951-501 1 ELECTRONICS MODULE ASSEMBLY for TEMPERATURE/UIO ISA100.11a
50016190-508 1 CAP ASSEMBLY, BATTERY, ALUMINUM, BLUE, EPOXY-POLYESTER POWDER
COAT
50015623-505 1 CAP ASSEMBLY, LCD, ALUMINUM, BLUE, EPOXY-POLYESTER POWDER
COAT
50026127-503 1 CAP ASSEMBLY, BATTERY, STAINLESS STEEL
50026009-502 1 CAP ASSEMBLY, LCD, STAINLESS STEEL
50031715-504 1 ANTENNA ASSEMBLY, 4 dBi INTEGRAL, ALUMINUM, EPOXY-POLYESTER
POWDER COAT
50031715-505 1 ANTENNA ASSEMBLY, 4 dBi INTEGRAL, STAINLESS STEEL
50018414-001 1 REMOTE OMNI-DIRECTIONAL ANTENNA, 8 dBi
50018415-001 1 REMOTE DIRECTIONAL ANTENNA, 14 dBi
50028364-504 1 ANTENNA ADAPTER ASSEMBLY, REMOTE, TYPE N, ALUMINUM, EPOXY-
POLYESTER
50028364-505 1 ANTENNA ADAPTER ASSEMBLY, REMOTE, TYPE N, STAINLESS STEEL
50018278-001 1 COAX CABLE ASSY, 1.0M ( 3.3 Ft) LONG, N-MALE - N-MALE
50018278-002 1 COAX CABLE ASSY, 3.0M (10.0 Ft) LONG, N-MALE - N-MALE
50018278-003 1 COAX CABLE ASSY, 10.0M (33.0 Ft) LONG, N-MALE - N-MALE
50018279-090 1 LIGHTNING SURGE ARRESTOR
50047517-501 1 I.S. BATTERY PACK HOUSING ASSEMBLY
50136118-501 1 24V EXTERNAL POWER MODULE
50026010-001 2 3.6V LITHIUM THIONYL CHLORIDE (Li-SOCI2) BATTERY
50026010-002 4 3.6V LITHIUM THIONYL CHLORIDE (Li-SOCI2) BATTERY
50026010-003 10 3.6V LITHIUM THIONYL CHLORIDE (Li-SOCI2) BATTERY
