Honeywell SmartLine STIW400 - Table 9-2: Angle and Flat Bracket Parts (Refer to Figure 9-1); Table 9-3: Transmitter Enclosure O-Ring Kit

9. Parts
8.8. Transmitter body
Revision 1 SmartLine Wireless Temperature and Universal I/O User's Manual 67
Table 9-2: Angle and Flat Bracket Parts (Refer to Figure 9-1)
Key
No.
Part Number Description
Quantity
Per Unit
1
50154109-501
Carbon Steel Angle Pipe Bracket Mounting kit for all models
1
2
50154109-503
316 Stainless Steel Angle Pipe Bracket Mounting kit for all models
1
3
50148944-501
Carbon Steel Pipe Bracket Mounting kit for all models
1
4
50148944-503
316 Stainless Steel Wall Bracket Mounting kit for all models
1
Table 9-3: Transmitter Enclosure O-Ring Kit
Key
No.
Part Number Description
Quantity
Per Unit
K7
30757503-007
Electronics enclosure seals kit. Kit includes:
O-ring for transmitter end caps
O-ring for housing adaptor to electronics housing
6
3
