Honeywell ST 3000 Installation Guide

1 of 4 34-ST-99-15 Addendum 4/02
Addendum to
ST 3000 Smart Transmitter
Release 300 and SFC Smart Field Communicator Model STS 103
Installation Guide
34-ST-33-39
Overview
Two new models have been added to the family of ST3000 Smart
Transmitters:
Gauge Pressure Model STG19L
Gauge Pressure Model STG99L.
Each of these has an Upper Range Limit (URL) of 10000 psi (690 bar),
which is significantly higher than previously available models. Also,
each of these new models has significantly higher ratings for Maximum
Working Pressure (10000 psi, or 690 bar) and Overpressure (15000 psi, or
1034 bar). The burst pressure is rated at 26000 psi (1793 bar).
Except for the higher operating range, each of these two new models
includes physical and functional features similar to those of closely
related family members (STG1xL and STG9xL). With the exceptions
noted in this addendum, all parts of User Manual 34-ST-33-39C apply to
these new models.
Because of the similarities between new and existing models, these new
devices can be used as direct replacements in circumstances that require
higher pressure capabilities.
Details of pressure ranges for these new models are specified in
“Additions and Changes to the Manual”, below.

Honeywell ST 3000 Specifications

General

Manufacturer	Honeywell
Category	Transmitter
Stability	±0.01% of URL per year
Operating Temperature	-40 to 85°C (-40 to 185°F)
Communication Protocol	HART
Housing Material	Aluminum or Stainless Steel
Enclosure Rating	IP66/67, NEMA 4X
Measurement Type	Gauge, Absolute, Differential
Output Signal	4-20 mA, HART
Process Temperature	-40 to 121°C (-40 to 250°F)
Hazardous Area Approvals	FM, CSA, ATEX, IECEx
Process Connection	1/2" NPT
Material	316L Stainless Steel, Hastelloy C
