Honeywell ST 3000 Installation Guide

References
Publication
Title
Publication
Number
Binder
Title
Binder
Number
ST 3000 Smart Transmitter Release 300
and SFC Smart Field Communicator
Model STS 103 User’s Manual
34-ST-25-14
SCT 3000 Smartline Configuration
Toolkit Start-Up and Installation Manual
34-ST-10-08
Smart Field Communicator Model
STS103 Operating Guide
34-ST-11-14
For R400 and later:
PM/APM Smartline Transmitter
Integration Manual
PM12-410 Implementation/
PM/APM Optional Devices
TDC 2045
Symbol Definitions
This CAUTION symbol on the equipment refers the user to the Product
Manual for additional information. This symbol appears next to required
information in the manual.
This WARNING symbol on the equipment refers the user to the Product
Manual for additional information. This symbol appears next to required
information in the manual.
WARNING: risk of electrical shock. This symbol warns the user of a potential
shock hazard where HAZARDOUS LIVE voltages greater than 30 Vrms, 42.4
Vpeak, or 60 VDC may be accessible.
ATTENTION, Electrostatic Discharge (ESD) hazards. Observe precautions for
handling electrostatic sensitive devices
Protective Earth (PE) terminal. Provided for connection of the protective earth
(green or green/yellow) supply system conductor.
iv ST 3000 Release 300 Installation Guide 2/05

Honeywell ST 3000 Specifications

General

Manufacturer	Honeywell
Category	Transmitter
Stability	±0.01% of URL per year
Operating Temperature	-40 to 85°C (-40 to 185°F)
Communication Protocol	HART
Housing Material	Aluminum or Stainless Steel
Enclosure Rating	IP66/67, NEMA 4X
Measurement Type	Gauge, Absolute, Differential
Output Signal	4-20 mA, HART
Process Temperature	-40 to 121°C (-40 to 250°F)
Hazardous Area Approvals	FM, CSA, ATEX, IECEx
Process Connection	1/2" NPT
Material	316L Stainless Steel, Hastelloy C
