2.3 Verifying Configuration Data
Procedure
Use the procedure in Table 3 to display all the basic transmitter database
parameters to be sure they are correct. Note that the values/selections
shown in displays are for example purposes only.
ATTENTION
• This procedure assumes that you have established communications
with the transmitter as outlined in Table 2.
• If any parameter is not set to the correct value/selection or your
transmitter was not configured, you can do so now. Refer to the
Configuration Section in the ST 3000 Smart Transmitter, Release 300
and SFC Smart Field Communicator Model STS 103 User’s Manual,
34-ST-25-14 for details.
Table 3 Verifying Transmitter’s Configuration Data (Using the SFC)
Step Press Key Read Display or Action Description
1
DE READ
A
ID
NON-VOL
ENTER
(Yes)
TA ON.G
?TRIPS SECURED?
TA ON.G
SFC WORK ING. . .
LIN AG NO.DP T
PT 1ØØ1S
This prompt only appears for
transmitters in analog mode.
This is only required for transmitters
in analog mode.
Transmitter’s assigned tag number
“SPT 1001” appears in bottom row.
2
C
DAMP
PT1DAMP
3ECØ
.O
1ØØ1
SD
S
NS
Present damping time setting.
Continued on next page
10 ST 3000 Release 300 Installation Guide 2/05

Honeywell ST 3000 Specifications

General

Manufacturer	Honeywell
Category	Transmitter
Stability	±0.01% of URL per year
Operating Temperature	-40 to 85°C (-40 to 185°F)
Communication Protocol	HART
Housing Material	Aluminum or Stainless Steel
Enclosure Rating	IP66/67, NEMA 4X
Measurement Type	Gauge, Absolute, Differential
Output Signal	4-20 mA, HART
Process Temperature	-40 to 121°C (-40 to 250°F)
Hazardous Area Approvals	FM, CSA, ATEX, IECEx
Process Connection	1/2" NPT
Material	316L Stainless Steel, Hastelloy C
