About This Publication
This manual is intended as a handy guide for installing ST 3000
®
Release 300 Smart Transmitters.
It provides data for checking out, mounting and wiring the transmitter as well as detailed wiring
diagrams for reference. Much of this same information is also included in the ST 3000 Smart
Transmitter Release 300 and SFC
®
Smart Field Communicator Model STS 103 User’s Manual
34-ST-25-14 which is the main reference document. We supply this information with each
transmitter as an aid in completing installation tasks as quickly as possible.
Procedures in this manual that involve using a Smart Field Communicator (SFC) to “talk” to the
transmitter are based on using our latest SFC Model STS103. You can also use the Smartline
Configuration Toolkit (SCT 3000) software program to perform transmitter configuration and
start up. The SCT 3000 contains an on-line user manual and help information that provides details
for setting up the transmitter.
If you will be digitally integrating the ST 3000 transmitter with our TotalPlant
®
Solution (TPS)
system, you will need to supplement this information with data in the PM/APM Smartline
®
Transmitter Integration Manual which is supplied with the TDC 3000
®X
bookset. TPS is the
evolution of TDC 3000
X
.
This guide does not apply to Series 100e, non Release 300 Series 100/900 and Series 600
transmitter models. If you have one of these ST 3000 Smart Transmitter Series, refer to the
Installation Guide and User’s Manual supplied with the transmitter for information.
Patent Notice
This product is covered by one or more of the following U.S. Patents: 4,520,488; 4,567,466;
4,494,183; 4,502,335; 4,592,002; 4,553,104; 4,541,282; 4,806,905; 4,797,669; 4,735,090;
4,768,382; 4,787,250; 4,888,992; 5,811,690; 5,875,150; 5,765,436; 4,734,873; 6,041,659 and
other patents pending.
2/05 ST 3000 Release 300 Installation Guide
iii
To Next Page
