1.2 Preliminary Checks, Continued
Communicating with
the ST3000
Transmitter, continued
Using the SFC:
If you ordered an SFC along with your transmitter, locate it and
follow the instructions supplied with the SFC Model STS103 to
prepare it for operation. Otherwise, be sure you have a fully
charged SFC Model STS103 on hand to check the operation of
your transmitter.
NOTE: SFC model STS103 with software version 5.0 or
greater is fully compatible with all Series 100 and 900,
Release 300, ST 3000 transmitters and smart meters.
The SFC will operate with transmitters that have older
software versions, but functions will be limited to
those applicable for the transmitter software.
If your SFC is a Model STS102 instead, you must refer to the ST
3000 Smart Field Communicator for Series 3000 Transmitters
Operating Guide 34-ST-11-10 for keystroke details.
Using the SCT:
The SCT 3000 Smartline Configuration Toolkit runs on a variety
of PC platforms using MS-DOS 5.0 or higher and Windows 95
©
,
Windows 98 and Windows NT 4.0. It is a bundled Microsoft
Windows software and PC-interface hardware solution that
allows quick, error-free configuration of Honeywell Smartline
field instruments.
NOTE: SCT 3000 software Release 3.12.2 or greater is
compatible with all Series 100 and 900, Release 300,
ST 3000 transmitters. Please contact your Honeywell
representative for more information.
Using reference data
The ST 3000 Smart Transmitter Release 300 and SFC Smart Field
Communicator Model STS 103 User’s Manual, 34-ST -25-14 was shipped
separately to a person designated on the order. The User’s Manual
contains complete configuration, operation, calibration, service, and
replacement parts information for the transmitter, so you may want to
have it on hand for reference. It also includes the same installation data
contained in this installation guide to minimize cross reference. But, the
optional bench check function and reference dimension drawings list are
included in this guide only.
Appendix A Smart Meter Reference contains configuration and
operating information for using the the ST 3000 when it is equipped with
the smart meter option (option SM).
4 ST 3000 Release 300 Installation Guide 2/05
